XM177E2 SOG

Factions	Weapon	Icon	Classes	Ammo
					US	XM177E2 SOG		Assault Radioman	30+1 / 90

Damage Base	Headshot ×	Chest ×	Stomach ×	Leg ×	Arm ×	Bayonet	Rifle Grenades	Reload Speed
								Partial	Empty
35	×2.5 = 87.5	×1.2 = 42	×1.15 = 40.25	×0.8 = 28	×0.75 = 26.25	NO	NO	2.366 Seconds	3.166 Seconds

Designation	Weapon Type	Fire Modes	Fire Rate	Bullet Spread °	Range Modifier	Muzzle Velocity	Projectile weight	Weight
				XM177E2 (R629 in US Army service)	Carbine	Auto+Semi	750 RPM	7.77° & 1.62° ADS	0.935	810 m/s	12.3g (189.818 gr)	2.43 kg (5.35 lbs)

Full name	Caliber	Place of Origin	Date	Manufacturer	Barrel Length	Total Length	Weapon Script Name
								Colt Commando Model 629	5.56mm	USA	1967	Colt	11.5 in (292 mm)	32.5 in (830 mm)	weapon_xm177

HISTORY

The Colt Commando was not initially part of the CAR-15 Military Weapons System, but was added in 1966 in response to the US military's desire for a shorter M16 and without the Model 607 SMG's inadequacies. Colt engineer Rob Roy designed a simpler two-position telescoping tubular aluminum buttstock to replace the complicated extending triangular version. The fragile and ad hoc triangular handguards were replaced by reinforced round handguards. Each half of the round handguard is identical, simplifying logistics by not requiring a top/bottom or left/right pair. The Model 609 Commando has a forward assist, while the Model 610 Commando does not. A Model 610B with a four-position selector was available, but not used by the U.S. military. All versions are equipped with the 4.25-inch (108 mm) long moderator.

The XM177 uses a unique flash suppressor sometimes called a flash or sound moderator for its 10-inch (250 mm) barrel. This device is 4.2 inches (110 mm) long and was designed primarily as a counterbalance measure as the shorter barrel makes the weapon unwieldy. This device reduces flash signature greatly and sound signature slightly, making the normally louder short barreled carbine sound like a longer barreled M16A1. Although it has no internal baffles and does not completely reduce the sound signature to subsonic levels, because it alters the sound level of the weapon, the US Bureau of Alcohol Tobacco Firearms and Explosives has declared this muzzle device to be a sound suppressor and regulates its civilian purchase in the United States.

The Model 610 was classified as the XM177 but adopted by the Air Force as the GAU-5/A Submachine Gun (GA denoting an automatic gun and U a complete unit rather than a parts kit: the popular "gun aircraft unit" and "gun automatic unit" explanations are backronyms). The Army purchased 2,815 Model 609 CAR-15 Commandos on June 28, 1966, which were officially designated Submachine Gun, 5.56 mm, XM177E1. As part of the contract, Colt was supposed to supply each XM177E1s with seven 30-round magazines, but Colt was unable to build a reliable 30-round curved magazine that would fit in the M16 magazine well, so most XM177E1s were shipped with 20-round magazines. The exception was 5th Special Forces Group, who received a total of four early 30-round magazines. Colt completed delivery of the purchased XM177E1s in March 1967.

In 1967, in response to field testing, Colt lengthened the Commando's barrel from 10 to 11.5 inches (254 to 292 mm). The increased length reduced noise and muzzle flash, and allowed fitting of the Colt XM148 grenade launcher. A metal boss was added to the moderator for mounting of the XM148 and rifle grenades. The chambers were chrome-plated. The Commandos with the longer barrels were called the Model 629 and Model 649. The Model 629 Commando has a forward assist; the Model 649 Commando does not.

In April 1967, the Army purchased 510 Model 629 Commandos for use by troops assigned to the Military Assistance Command, Vietnam Studies and Observations Group (MACV-SOG), and designated them XM177E2. Delivery was completed by the end of September 1967. The Air Force adopted a similar model without the forward assist feature as the GAU-5A/A. Sources debate whether or not this was a Colt Model 630 or Model 649. According to John Plaster and other sources, the lack of 30-round magazines continued to be problematic and SOG operators resorted to pooling their personal resources and purchasing the larger capacity magazines on the civilian U.S. market. Problems with range, accuracy, barrel fouling, and usage of tracer bullets continued to plague the XM177 series, but Colt estimated that it would take a six-month $400,000 program to do a complete ballistic and kinematic study. There were also recommendations for a 29-month $635,000 research and development program. Both recommendations were declined by the U.S. military as American ground force involvement in the Vietnam War was gradually winding down. Production of the CAR-15 Commando ended in 1970.
SOURCE

---

•

  Reproduction

•
•
•
•

  CAR-15 (XM177E1) as tested in 1966

---
